D Miningwell Geotechnical Drilling Rock Core Drilling Diamond Drill Rig: Professional Equipment for Precise Exploration

D Miningwell’s Geotechnical Drilling Rock Core Drilling Diamond Drill Rig is a high-performance professional device tailored for exploration scenarios. It excels in mine exploration, geological sampling, and blast hole drilling, providing reliable technical support for geological surveys, resource exploration, and engineering construction projects. Whether for mineral resource prospecting or geotechnical engineering data collection, this rig meets the high standards of precision and efficiency required in the industry.

Rated 4.7/5 based on 364 customer reviews
Share:
Next:
Content

Core Features of D Miningwell Diamond Drill Rig

The drill rig stands out in the market with its advanced technology and humanized design, mainly reflected in the following key advantages:
  1. High-Performance Power Head: Manufactured using the industry’s advanced production processes, the power head is designed to handle both high-torque and high-speed drilling operations. It delivers strong power output while maintaining a compact structure, ensuring stable performance even in complex geological environments.
  2. Unique Balanced Pressure Drilling System: This industry-exclusive system effectively balances the weight of the drill string and precisely controls drilling pressure. It enables the rig to adapt to diverse complex formation conditions and meet the technical requirements of deep-hole drilling, greatly improving drilling accuracy and efficiency.
  3. Integrated Electro-Hydraulic Central Control System: As a unique design in the industry, the manual console centrally controls all power operations and drilling processes. It also provides real-time monitoring of the machine’s operating status, simplifying operation and enabling quick fault diagnosis. Additionally, the drill pipe gripper is equipped with an automatic pressure-maintaining and clamping function, which can be synchronized with the chuck-type power head for fast response, ensuring safe and reliable operation.
  4. Proprietary Mud Processing System: Equipped with a customized high-pressure mud pump (model: BW 90-3), the system features light weight and low pulse. It can efficiently handle high-solid-phase mud and circulating mud, maintaining smooth drilling and protecting the drill bit and drill string.
  5. Efficient Hydraulic Oil Pump: The high-performance hydraulic oil pump offers high efficiency, fast response, and stable pressure output. It provides consistent power support for the entire rig’s hydraulic system, ensuring smooth operation of all components.

Technical Parameters of D Miningwell Diamond Drill Rig

Parameter Category Specification Parameter Category Specification
Drilling Depth 600 m Overall Dimension (L×W×H) 4600×2000×2350 mm
Machine Weight 6.7 T Drilling Diameter 60-110 mm
Power 96 Kw Mud Pump Model BW 90-3
Gradient Adaptability 30° Walking Speed 2.5 Kw
Drill Pipe Length 1.5 m Lifting Force 10 T
Rotation Speed 0-1200 rpm Drilling Angle Range 45-90°

Key System Advantages

  • Hydraulic Fixture System: Supports 45-90° right-angle or inclined drilling, ensuring stable and safe operation during angle-adjustable drilling tasks, which is suitable for diverse geotechnical exploration needs.
  • Intelligent Operating System: The integrated electro-hydraulic control not only simplifies the operation process but also enhances the safety and controllability of the equipment. Operators can grasp the rig’s status in real time, reducing operational errors and maintenance time.
For more detailed information about the D Miningwell Geotechnical Drilling Rock Core Drilling Diamond Drill Rig, please visit the official website: www.dminingwell.com
