Piston air compressor JA30D

Brand Name: D miningwell
Certification: CE, ISO
Minimum Order Quantity: 1 set
Packaging Details: 40HQ-20GP
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, Western Union

Diesel Portable Piston Air Compressor Mobile for Jack Hammer / Mining
1.Simple structure,light weight,easy to move .
2.Easy operating and maintenance.
3.High quality air delivery.
4.Superior technology,Low cost .

Inquiry Now

Send Email

Product Introduction

Show details

Technical data

Related cases

Product Introduction

Diesel Portable Piston Air Compressor Mobile for Jack Hammer / Mining
1.Simple structure,light weight,easy to move .
2.Easy operating and maintenance.
3.High quality air delivery.
4.Superior technology,Low cost .
5.Valve plate and spring strip:made of special steel from Sweden and after special treatment.
6.Piston ring:special design;integral casting;excellent flexibility;lowest lubricating oil consumption
7.Cylinder:made of boron cast iron;wear resistant;special suitable for dusty condition
8.Cylinder cover:extrusion process adopted;streamlined external appearance;good heat emission performance.
9.High efficiency and low consumption.
10.Stable and smooth running with anti-vibration frame.
11.Professional design and Special manufacturing.
12.Energy saving.

Show details

Technical data

型号Model		JA18D-8	JA200-8	JA30D-8	JA40D-B	JA20B-8	JA30B-8	JA30B-10	JA40B-8
机组 Machine unit	驱动功率Power(KW)	18.5	22	30	45	22	30	22	45
	排气压力PressurePressure(bar)	8						10	8
	排气量F.A.D(mVmin)	2.85	3.6	5.0	7.4	3.6	4.8	3.6	7.4
	传动方式Drive Style	直联Direct				皮带Belt
	冷却方式Cooling Method	风冷Air Cooling
	输气接口0utlet Dimeter	G1	G1	G11/4	G11/2	G1	G11/4	G1	G11/2
	长Length(mm)	1450	1450	1750	1900	1500	1500	1500	1840
	宽Width(mm)	730	730	810	960	800	800	800	880
	高Hight(mm	930	930	1080	1460	920	920	920	1200
	整机重量Total Weight(kg)	350	360	480	700	360	480	360	700
