Mud pump BW 320

BW320 mud pump are mainly used for irrigation agricultural machinery.the main characteristic is the high pressure,lift much,less energy consumption,easy operation,high quality and durable ,easy to move,especially for mountain terraces of irrigation.
Product Introduction
Drilling rig and mud pump application range:
1.Projects: Construction drilling of the projects e.g. prospection, geotechnical investigation(geological exploring), railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction;
2. Exploration: Coal mining exploration, Ore exploration;
3. Water well : Small hole diameter water well drilling;
4. Pipe-installing : Geothermal pipe-installing for heat pump;
5. Foundation piling: Small-diameter hole foundation piling drilling.
They are also the main equipment of the geological survey,the main role in the process of core drilling boreholes is to supply fluid(mud or water),making it circulate during drilling and carry rock waste back to the ground,in order to achieve and maintain the bottom hole clean and lubricate drill bits and drilling tools with cooling.
BW-320 Mud Pumps is equipped with drilling rigs to drill holes with mud. During drilling mud pump pumps slurry to the hole to provide coat to the wall, to lubricate the drilling tools and to carry the rock debris up to the ground. It is applied to geological core drilling and prospecting drilling with depth less than 1500 meter.
All our mud pump can be driven by electric motor,diesel engine,hydraulic motor.
Show details
Technical data
Technical Parameters
Type BW320
Horizontal three cylinder reciprocating
single acting piston pump
Cylinder dia.(mm) 80
Stroke(mm) 110
Pump Speed(times/min) 214 153 109 78
Flow(L/min) 320 230 165 118
Pressure(Mpa) 2.2 3.6 6.2 10
Power(Kw) 45
Dimension(mm) 1905*1100*1200
Weight(kg) 720
