Diesel portable screw air compressor KSCY Series

Brand Name: D miningwell
Certification: CE, ISO
Minimum Order Quantity: 1 set
Packaging Details: 40HQ-20GP
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, Western Union

KAISHAN KSCY Diesel portable Screw Air Compressor adopts 0-100% infinitely variable control of Capacity to realize optimal energy saving effect.
Product Introduction
Design Characteristics of Screw Rotor Profile:
1. It fully realizes "Convex-Convex" engagement to assist in the formation of hydrodynamic lubrication film, to reduce horizontal leakage passing the contact zone, and to improve efficiency of the compressor; improve rotor processing and testing property.
2. It adopts the design thought of "large rotor, large bearing and low speed method", thus its revolving speed is 30-50% lower than that of other brands to reduce noise, vibration, and exhaust temperature, improve rotor rigidity, increase service life, and reduce sensibility to sundries and oil carbide.
3. Its power range is 4~355KW, where 18.5~250KW applies to the compressor without direct-coupled gearbox, 200KW and 250KW apply to the compressor with Level 4 direct-coupled motor and the speed is as low as 1480 rmp.
4. It fully conforms to and exceeds requirements in GB19153-2003 Limited Values of Energy Efficiency and Evaluating Values of Energy Conservation of Capacity Air Compressors.
Diesel portable screw air compressor, which are widely used in highway, railway, mining, water conservancy, shipbuilding, urban construction, energy, military industry and other industries.
Show details
Technical data
Model Air pressure(bar) Air capacity(m³/min) Engine model(kW) Dimension(mm) Weight(kg)
KSCY-360/13 13 10 Yuchai110 4000*1900*2300 2300
KSCY-425/10 10 12 Yuchai110 4000*1900*2300 2300
KSCY-460/14.5 14.5 13 Cummins132 4000*1900*2300 2600
KSCY-550/13 13 15 Cummins132 3300*1600*2400 3000
KSCY-550/13 13 15 Yuchai176 3300*1600*2400 3000
KSCY-580/17 17 17 Cummins 194 3900*1700*2400 3400
KSCY-680/14.5 14.5 19 Cummins 194 3900*1700*2400 3400
