D Mininwell S100T Screw Air Compressor 31 m3/min 25 bar 309 kW Diesel Compressor

This series of products is designed for Wells and geothermal projects and related compressed gas stations that require Φ115-254mm Wells drilling rigs.The S100T compressor is capable of generating high-pressure air up to 25Bar, which is suitable for operating environments that require highly pressurised air. With an air flow rate of 1000 cfm (approximately 31 cubic metres per minute), the S100T compressor ensures a constant supply of air during intensive operations. The range has been upgraded and optimised for continuous use and transport size requirements. Upgraded and optimised for continuous use and transport size requirements. More durability and lower fuel consumption.

Rated 4.9/5 based on 247 customer reviews
Share:
Content

Chico S100T screw air compressor needs to pay attention to the following points in the process of using:

1. check the cooling system: make sure the cooling effect of the cooler is good, clean the dust and debris on the surface of the cooler.
2. check the electrical system: make sure the components are working properly and functioning well.
3. change the air filter regularly: prevent dust and impurities from entering the compressor and affecting the quality of compressed air.
4. Replace the oil filter regularly: prevent the oil filter from clogging and impurities from contaminating the oil circuit and affecting the performance of the compressor.
5. Regular replacement of the oil-air separator core: to prevent the oil separator core resistance increases, fire and other safety accidents; to prevent the oil separator core efficiency to reduce the machine running oil.
6. check and replace the belt (if any): check the tension and wear of the belt, if the belt is slack or badly worn, it should be replaced in time.
7. check and tighten the bolts: regularly check the equipment fixed parts intact and firmly installed.
8. check the control system: ensure the stable operation of the equipment.
9. keep the lubricating oil in the oil pool within the scale range, and check that the oil level in the oil filler should not be lower than the scale value before operation.
10. check whether the moving parts are flexible, whether the joint parts are tight, whether the lubrication system is normal, whether the motor and electrical control equipment are safe and reliable.
11. check whether the exhaust pipe is smooth.
12. Turn on the water supply, open the water inlet valve to make the cooling water unobstructed.
13. Before starting for the first time after a long period of disablement, the machine must be checked in a disc, paying attention to the phenomena such as whether there is any impact, jamming or abnormal sound.
14. The machine must be started without load, and then gradually make the air compressor enter into load operation after normal no-load operation.
15. After normal operation, pay attention to the readings of various instruments and adjust them at any time.
16 Check whether the temperature of the motor is normal and whether the readings of each meter are within the specified range. 17 Whether the running sound of each machine part is normal or not.
17. whether the running sound of the machine parts is normal. 18.
18 Whether the suction valve cover is hot, whether the sound of the valve is normal.
19. Whether the various safety protection equipment of the air compressor is reliable.

Following these precautions will help ensure the safe, stable and efficient operation of Chigo S100T screw air compressor.

Model Rated FAD Rated Pressure Engine Air End Weight L*W*H
S60 18 m3/min 18 bar 162 kw Single stage compression 3000 kg 3220*1670*1950
S60T 18 m3/min 18 bar 162 kw Two stage compression 3000 kg 3220*1670*1950
S85T 24 m3/min 22 bar 228 kw Two stage compression 3450 kg 3560*1830*2050
S85T-II 24 m3/min 22 bar 239 kw Two stage compression 3450 kg 3560*1830*2050
S95T 29 m3/min 24 bar 295 kw Two stage compression 4300 kg 3950*2000*2300
S95T-II 29 m3/min 24 bar 295 kw Two stage compression 4300 kg 3950*2000*2300
S98T 30 m3/min 24 bar 295 kw Two stage compression 4350 kg 3950*2000*2300
S98T-II 30 m3/min 24 bar 295 kw Two stage compression 4350 kg 3950*2000*2300
S100D 31 m3/min 25 bar 309 kw Two stage compression 4600 kg 3960*2000*2000
S100T 31 m3/min 25 bar 309 kw Two stage compression 4500 kg 3960*2000*2000
S100T-II 31 m3/min 25 bar 309 kw Two stage compression 4500 kg 3960*2000*2000
S125D 36 m3/min 30 bar 410 kw Two stage compression 5500 kg 4220*2000*2300
